   1985.5 Ignition Lock Replacement
« Previous topic | Next topic »
Pages: 1  Reply Reply Notify of replies Notify of replies Send Topic Send Topic Print Print
   Author  Topic: 1985.5 Ignition Lock Replacement  (Read 1627 times)
944up996
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 3
1985.5 Ignition Lock Replacement
« on: Apr 26th, 2010, 6:17pm »
Quote Quote Modify Modify

Pulled the key out the other day and the lock didn't engage as normal.  Tried turning the wheel to engage but nothing.  Key will not go back in ignition.  Got a new lock cylinder and started disassembling this weekend but figured out that this may be bigger than thought.  How do you remove the ignition lock on this model?  It's not what's in Haynes or Clarks Garage.
IP Logged
AlsChips
944online Forum Full Member
***




Now with More Rant!




Posts: 412
Re: 1985.5 Ignition Lock Replacement
« Reply #1 on: Apr 26th, 2010, 11:05pm »
Quote Quote Modify Modify

I replaced my cylinder in my blog. Theres instructions and pics.


"Got my old car back with pics"  Its in the 944 blog section, second page or so.
IP Logged

Smiles Per Gallon
Fanboy
944up996
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 3
Re: 1985.5 Ignition Lock Replacement
« Reply #2 on: Apr 27th, 2010, 7:50am »
Quote Quote Modify Modify

Thanks for the reply but it looks like it's the same solution as I've seen before for early 944's whereas I have a later model.  I don't doubt that the housing has to be drilled to unlock the lock cylinder but getting the housing out is the problem.  Is removal of the entire steering column the answer?
IP Logged
mikes86944
944online Forum Senior Member
****



I love Forum 1G - SP1!




Posts: 585
Re: 1985.5 Ignition Lock Replacement
« Reply #3 on: Apr 27th, 2010, 6:49pm »
Quote Quote Modify Modify

I think I am reading your post correctly...to remove the switch housing from the steering column..two "sheer bolts" hold it on to the column.  Have to drill out and reinstall with new sheer bolts.
IP Logged
n_hall
944online Forum Senior Member
****



elk grove village illinois


Email

Posts: 743
Re: 1985.5 Ignition Lock Replacement
« Reply #4 on: Apr 27th, 2010, 7:02pm »
Quote Quote Modify Modify

use old cv axle bolts, they're the same threading and have a good length to them.
IP Logged

85.5 944 with 89 2.7L

“Whatever it is, the car has to look good. If your car doesn’t look good, sound good, and feel good, you’re not going to drive it like you should.”

- Akira Nakai
Grandpa#3
944online Forum Senior Member
****



USAF Retired / Civil Service Retired "GO BLUE"


Email

Posts: 1812
Re: 1985.5 Ignition Lock Replacement
« Reply #5 on: Apr 27th, 2010, 8:57pm »
Quote Quote Modify Modify

In order to remove the two bolts use a Dremel Tool with a cut off wheel to cut a notch across the bolt end and turn out with a stubby screw driver. Do it on one end or the other, whichever is easiest for you. Check out the link below as it will show you where to drill to remove lock cylinder.

http://forums.rennlist.com/rennforums/944-turbo-and-turbo-s-forum/213552 -how-to-remove-ignition-switch.html?highlight=ignition+lock+drill+location

Cheers,
Larry   Smiley
« Last Edit: Apr 27th, 2010, 9:04pm by Grandpa#3 » IP Logged

Use Spell Check and you will always bee right.
Half way between Perry and Hawkinsville, Georgia
1985.5 944 n/a Graphite Metallic, a work in progress.
1992, 968 Horizon Blue Cab

944up996
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 3
Re: 1985.5 Ignition Lock Replacement
« Reply #6 on: May 3rd, 2010, 8:13am »
Quote Quote Modify Modify

After looking at your pics and dreading the idea of cutting a notch across the bolt ends to remove the lock housing I came up with another solution.  Years ago I had found a 90 degree drill adapter for 1/4 inch hex bits.  Using the adapter and a shortened bit I was able to drill the hole necessary to remove the lock cylinder.  After removing the cylinder, cleaning and working it for a while I was able to reinstall it rather than replace it.
IP Logged
