   Suspected DME Problem -.- HELP!
« Previous topic | Next topic »
Pages: 1 2 3  4 Reply Reply Notify of replies Notify of replies Send Topic Send Topic Print Print
   Author  Topic: Suspected DME Problem -.- HELP!  (Read 2904 times)
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Suspected DME Problem -.- HELP!
« on: Aug 16th, 2011, 11:33pm »
Quote Quote Modify Modify

Embarassed i have done a lot of research, bought my car recently, (1984 944 N/A) and it broke down 3 days later, brand new battery and clean connections, yet, i turn the key over and i hear a single click in the engine and then a faint buzzing noise from the back bottom of the car(suspected buzzing to be the fuel pump but im not sure) and i have pulled my DME relay and resoldered the connections, please help!! lol  thank you
IP Logged

First car - 84 944 -
NeunVierVier
944online Forum Full Member
***




Proponent Of Perverted German Engineering




Posts: 475
Re: Suspected DME Problem -.- HELP!
« Reply #1 on: Aug 17th, 2011, 12:53am »
Quote Quote Modify Modify

Hi!
As a new owner, you MUST read these links:
Clark's Garage has an outstanding no-start troubleshooting guide.
http://www.clarks-garage.com/shop-manual/repair-procedure-index3.htm

Pretty much all the basics you need to know about your car:
http://www.944online.com/cgi-bin/forum/forum.cgi?board=944Talk;action=di splay;num=1298752427



This sounds like a potential problem with your starter motor.  If your engine is not turning at all, this might be at fault.

Quote:
i turn the key over and i hear a single click in the engine and then a faint buzzing noise from the back bottom of the car(suspected buzzing to be the fuel pump but im not sure)


I would suspect a fuel pressure problem IF the car was rotating but not starting.  But it's not rotating from your description.  So I would inspect the starter motor; its mechanical operation AND its electrical connections.

How exactly did the car "break down"?
Cheers,
Jacob
IP Logged

-Jacob

1987 Porsche 944 Super Variant, zermatt gray

"Buying a car because it's reliable is like marrying someone because they are punctual." -Jeremy Clarkson

porschecidal_maniac
944online Forum Guru
*****




Maniac Racing - You're never too old to play cars.


WWW Email

Posts: 5609
Re: Suspected DME Problem -.- HELP!
« Reply #2 on: Aug 17th, 2011, 8:23am »
Quote Quote Modify Modify

single click sounds more like your starter or starter solenoid. Am I correct in interpreting your post as the car isn't cranking?

I would also check the battery connections. I understand it's new, but check your cables. You can also put the car up, undo the battery cables and then go under the car and remove, clean and replace the cables to your starter and alternator (the primary from the alternator goes directly to the starter)...

If you do these steps and the car does the same thing, the next place I would look is at the ignition switch. A bad ignition switch won't make contact on certain terminals and it may not be sending a start signal to the DME, and it may not be sending voltage through the alternator and to the starter.

A single click sounds like a starter issue or possibly an ignition switch, but not a DME problem.
IP Logged

- Jason

R7 Racing & Restoration
Maniac Racing
www.maniacracing.net
porschecidal_maniac
944online Forum Guru
*****




Maniac Racing - You're never too old to play cars.


WWW Email

Posts: 5609
Re: Suspected DME Problem -.- HELP!
« Reply #3 on: Aug 17th, 2011, 8:24am »
Quote Quote Modify Modify

one more thing - don't resolder the connections on your DME relay, buy a new one they are cheap and critical.
IP Logged

- Jason

R7 Racing & Restoration
Maniac Racing
www.maniacracing.net
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #4 on: Aug 17th, 2011, 8:38am »
Quote Quote Modify Modify

Thank you very much both of you!! i am off to work now but i will read those links soon! Smiley and the car is not cranking however i have taken the starter and solenoid into O'reilleys(spelling) and they tested it and said there was no problem with either component, and whit the cleaning cables, i cleaned the starters cables as well as the battery's when i had the starter taken off.
Thank you sooo much for your help guys!!!!! Cheesy
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #5 on: Aug 17th, 2011, 8:40am »
Quote Quote Modify Modify

and the starter was the first thing friends told me to check, and thank you for telling me that it isnt the DME, i was completely set on that diagnosis. however i am a broke highschool student so ill have to buy a new one soon.
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #6 on: Aug 17th, 2011, 8:44am »
Quote Quote Modify Modify

sorry so many posts, but the last thing, it was almost out of gas, so i dumped a gallon in, and drove my friend up the road to show him the car, i drove it pretty hard, then(my shift knob is very loose for 3rd and 4th, is this normal?) and i started my car in 3rd gear from a stop, that didn't sound too healthy, and 2 miles from my house i shut it down at my friends house, and 30 seconds later when i was about to head home, my car clicked and buzzed, haha. so that's my story, hopefully the new information proved helpfulCheesy thank you!!
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #7 on: Aug 17th, 2011, 8:48am »
Quote Quote Modify Modify

I understand jump starting is unhealthy, yet i wanted it to run so i tried that when it first broke down, that was my first diagnosis, that didn't work, i then pushed it and popped the clutch to get it home and it felt bogged down, now it wont even push start. Sad
IP Logged

First car - 84 944 -
Ronin-951
944online Forum Guru
*****




Masterless Pirate




Posts: 5542
Re: Suspected DME Problem -.- HELP!
« Reply #8 on: Aug 17th, 2011, 9:25am »
Quote Quote Modify Modify

Clean your grounds - standard advise to newcomers as 25 years of corrosion is tough to conduct electricity through. Yes, agree that it sounds like a connection problem to your starter, one of our esteamed members, Ramius968, sells a complete primary wire set and is recomended if the wire is in bad shape. Some engine bay pics would be nice for us to see what kind of shape the car is in generally. If you have squeeze wire type battery post connectors - Bingo!
IP Logged

'Princess' of the Inland Empire, virgin '86, Lady in the City, Ho on the Hiway, Pace not Race!
sstrickstein
944online Forum Senior Member
****




Gearheads Rule


WWW

Posts: 696
Re: Suspected DME Problem -.- HELP!
« Reply #9 on: Aug 17th, 2011, 5:45pm »
Quote Quote Modify Modify

Not sure if that is similair to the 1980 924 I have but it did the same thing. It turned out to be a bad ground wire from the alternator and from the battery to the chassis.
IP Logged

"Atomic Batteries to Power, Turbines to Speed, Ready to move out!"

1986 944 NA black/black
1984 928S Flying Purple People Eater
2000 911 Carerra cabriolet
1980 924 turbo-gone but not forgotten&
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #10 on: Aug 18th, 2011, 8:22pm »
Quote Quote Modify Modify

on Aug 17th, 2011, 9:25am, Ronin-951 wrote:
If you have squeeze wire type battery post connectors - Bingo!


i don't know what that means im sorry, but good advise, thank you. i will try and upload some pics to this forum for you guys.

and sstrickstein, i will look into that, thank you as well.

i just got back to my house, and remembered that the car wont even push start any more, it did twice since it and now it wont, i can hear that exhaust(custom) light up for a second then i hit the clutch and gas simultaneously and it dies quicker >:
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #11 on: Aug 18th, 2011, 8:25pm »
Quote Quote Modify Modify

oh ye! and another update i forgot to just post! I can turn the key to [on] and the throttle clicks, then when i turn to [start] the solenoid engages(yet the starter refuses to spin, and i have dis assembled it and it is not locked up, i could turn it with my fingers) then when i release the key to [on] the starter clicks again(i think the solenoid un-engaging) and then when i turn the key to [off] my throttle clicks again, and now there is no buzzing from the suspected fuel pump. i think i broke my DME relay so i will replace that soon, until then, ill hot wire it to test your guys' advice thanks;D
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #12 on: Aug 18th, 2011, 8:49pm »
Quote Quote Modify Modify

Engine pics on the way soonSmiley
(i dont know how to add pics, first forum Embarassed )
IP Logged

First car - 84 944 -
Undrgrnddub
944online Forum Junior Member
**



1984 Porsche 944 ^.^ first car




Posts: 53
Re: Suspected DME Problem -.- HELP!
« Reply #13 on: Aug 18th, 2011, 9:46pm »
Quote Quote Modify Modify

Please tell me how to posts the images directly to my thread, thank you Cheesy
http://imageshack.us/photo/my-images/228/944x1.jpg/
http://imageshack.us/photo/my-images/830/944onjacks.jpg/
http://imageshack.us/photo/my-images/59/944bodydamage.jpg/
http://imageshack.us/photo/my-images/827/944engine.jpg/
http://imageshack.us/photo/my-images/690/944battery.jpg/
http://imageshack.us/photo/my-images/97/944starter.jpg/
« Last Edit: Aug 18th, 2011, 9:47pm by Undrgrnddub » IP Logged

First car - 84 944 -
sstrickstein
944online Forum Senior Member
****




Gearheads Rule


WWW

Posts: 696
Re: Suspected DME Problem -.- HELP!
« Reply #14 on: Aug 18th, 2011, 10:46pm »
Quote Quote Modify Modify

First thing I would do is dump the k&n open air filter. They dont ad any Horsepower and let lots of dirt in your engine. If you dont have one or cant afford one and if a 944/2 box will work I will donate the extra one I have.
« Last Edit: Aug 18th, 2011, 10:49pm by sstrickstein » IP Logged

"Atomic Batteries to Power, Turbines to Speed, Ready to move out!"

1986 944 NA black/black
1984 928S Flying Purple People Eater
2000 911 Carerra cabriolet
1980 924 turbo-gone but not forgotten&
