   Tachometer Not Working
« Previous topic | Next topic »
Pages: 1  Reply Reply Notify of replies Notify of replies Send Topic Send Topic Print Print
   Author  Topic: Tachometer Not Working  (Read 1844 times)
frodos
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 34
Tachometer Not Working
« on: Aug 22nd, 2011, 7:53am »
Quote Quote Modify Modify

Just got back my car from the mechanic after a couple of weeks and it runs.  It still has some issues such as a bit of hesitation and stuttering when you give it some welly but I drove it 800 miles the other day and it was a blast.  I will deal with the stuttering later on once I figure out what RPM levels it does it at, but I can't do that until I get my tach to work.

All the gauges with the exception of the  odometer and tach seem to work.  Because the trip odometer is set at zero I assume it doesn't work because the previous owner tried to reset it while the car was moving.  This problem should be easy enough to tackle.

Anyone have any clues on how to get the tachometer up and running or is it going to require replacing the whole cluster?  Also  I remember reading that there is a company that sells LED kits for the cluster but I can't recall what it is called.  The cluster lights are way too dim and you can barely see them at night so i figure when I go in there to fix the tach and odometer I can install those as well.

As always, thank you all for you help.
IP Logged
Avimgod
944online Forum Senior Member
****




Ahhh... the internet... wonderful anonymity..


Email

Posts: 584
Re: Tachometer Not Working
« Reply #1 on: Aug 22nd, 2011, 8:52am »
Quote Quote Modify Modify

You can try to remove / clean the contacts on / and reinstall the gauge cluster.. you can also try cleaning the 24 pin connector on the firewall just above the brake booster.

Otherwise you might need a new tachometer.. odometer is likely a broken gear, easy fix!
IP Logged

I wish I could afford a Porsche wheel, much less a whole dang car!

hpservertech
944online Forum Guru
*****





  hpservertech


Posts: 4618
Re: Tachometer Not Working
« Reply #2 on: Aug 23rd, 2011, 10:31am »
Quote Quote Modify Modify

You can reset the trip when the car is moving.  It is a big myth that you can.  If the gear is bad it's bad and resetting the trip wont effect it.  Pull your cluster out (you CAN do it without taking the steering wheel out).  Follow www.clarks-garage.com and you will be ok.
IP Logged

86 Metallic Grey on Burgundy
85.5 Metallic graphite - Being changed into a dedicated track car - Sold
86 951 - Project car right now
IAN - 944ONLINE
944online Forum Moderator
admin center
944online Forum Guru
*****






  ianporsche
WWW Email

Posts: 9414
Re: Tachometer Not Working
« Reply #3 on: Aug 25th, 2011, 2:18pm »
Quote Quote Modify Modify

the guys that bring you this great forum
also sell parts  - thats how they are able to keep it up and running -
they do have the LED lights for the dash -
either just three main bulbs or as in kits with reflector fixes as well





its easy to do - and as you will have the cluster out then replace the odo gear at the same time -

mph ?
or kmh ?



and yes the gear comes with instructions

also
as your car hesitates when you stick the welly in
you should look at this as the fix
very very very common problem
did I say its a common problem ?
happens all the time ?
happened on my own car ?
how did I fix it  ?

click on this link for the fix

http://www.944online.com/cgi-bin/forum/forum.cgi?board=944electrical;act ion=display;num=1295013284

tach not working ?
check the connection at the baclk of the cluster when you have it out to replace the odo gear and the bulbs
if thats not it
maybe one of the ref sensors
either bad
or the connectors are bad


IP Logged

e mail
ian@944online.com
phone
toll free in the USA 1 866 944 7883
outside the USA
1 954 968 3766
FAX -1 954 968 3798
frodos
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 34
Re: Tachometer Not Working
« Reply #4 on: Aug 26th, 2011, 8:42pm »
Quote Quote Modify Modify

Sorry Ian, I completely forgot about that even though I called your office last week looking for something.

Sadly the car had an unfortunate run in with a tree a couple of days after I got it back from the mechanic (I drove it for all of two days) and has been totaled.  I am saddened but I am picking up another one next week so I will be coming to you to buy some parts.  I am thinking of starting with the under hood padding.
IP Logged
hankmann
944online Forum Newbie
*



I love Forum 1G - SP1!




Posts: 1
Re: Tachometer Not Working
« Reply #5 on: Sep 5th, 2011, 10:52am »
Quote Quote Modify Modify

Call Hollywood speedometer 1 818 2615136. I had mine repaired excellent priced right
IP Logged
River
944online Forum Guru
*****




1988 Celebration Edition




Posts: 3631
Re: Tachometer Not Working
« Reply #6 on: Sep 5th, 2011, 9:53pm »
Quote Quote Modify Modify

Ian,

so if one sensor is bad, it'll give the tach a bad time? I replaced the reference, but not the speed (speedometer works just fine).

IP Logged
hpservertech
944online Forum Guru
*****





  hpservertech


Posts: 4618
Re: Tachometer Not Working
« Reply #7 on: Sep 5th, 2011, 11:05pm »
Quote Quote Modify Modify

Speedometer isn't driver by the speed sensor next to the ref sensor.  Completely seperate system & purpose.
IP Logged

86 Metallic Grey on Burgundy
85.5 Metallic graphite - Being changed into a dedicated track car - Sold
86 951 - Project car right now
River
944online Forum Guru
*****




1988 Celebration Edition




Posts: 3631
Re: Tachometer Not Working
« Reply #8 on: Sep 6th, 2011, 4:51am »
Quote Quote Modify Modify

on Sep 5th, 2011, 11:05pm, hpservertech wrote:
Speedometer isn't driver by the speed sensor next to the ref sensor.  Completely seperate system & purpose.



That's what I figured. Had to ask the dumb question though. I still can't figure out why it's giving me grief. All the contacts in there are clean. (grounds haven't been done yet in there/didn't know they where in there). Still, nothing else is effected. Just looked up new tachs (and properly had a heart attack). lol!

IP Logged
hpservertech
944online Forum Guru
*****





  hpservertech


Posts: 4618
Re: Tachometer Not Working
« Reply #9 on: Sep 6th, 2011, 12:35pm »
Quote Quote Modify Modify

There is a gear/sensor at the transmission, converts things to an electrical signal which drives the speedometer/odometer/trip.

Ian might have a used tach, otherwise there is always evilbay.
IP Logged

86 Metallic Grey on Burgundy
85.5 Metallic graphite - Being changed into a dedicated track car - Sold
86 951 - Project car right now
River
944online Forum Guru
*****




1988 Celebration Edition




Posts: 3631
Re: Tachometer Not Working
« Reply #10 on: Sep 7th, 2011, 3:30pm »
Quote Quote Modify Modify

hmmm...

maybe it's slightly dirty? Corroded?

It used to work fine, then over the last few months not as much tach bounce. So I changed the ref sensor thinking it would fix it. Nope. It does work though once you get going.

IP Logged
hpservertech
944online Forum Guru
*****





  hpservertech


Posts: 4618
Re: Tachometer Not Working
« Reply #11 on: Sep 7th, 2011, 4:44pm »
Quote Quote Modify Modify

sounds like it...or a bad ground.
IP Logged

86 Metallic Grey on Burgundy
85.5 Metallic graphite - Being changed into a dedicated track car - Sold
86 951 - Project car right now
